PLC Control Double Layer Forming Machine Hydraulic Pressure Transmission

  • 1
  • 2
  • 3

Place of Origin : CHINA

Brand Name : HENGFU

MOQ : 1 Piece

Packaging Details : Plastic Film & Steel Wire Fixed

Delivery Time : 45Days

Payment Terms : 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment

Tile Type : Colored Steel

Certification : CE, SGS

Condition : New

Customized : Customized

Usage : Roof, Wall, Floor

Transmission Method : Hydraulic Pressure

Transmission Mode : One Inch Chain

Cutting Method : Shear of Guide Column

Transport Package : Plastic Film & Steel Wire Fixed

Specification : 6500mmx1300mmx1200mm

Package Size : 650.00cm * 130.00cm * 120.00cm

Package Gross Weight : 7000.000kg

Contact Now

Intelligent Easy-Operate 840-900 Double Layer Roll Forming Machine

The Double Layer Roll Forming Machine integrates two independent roll forming models into one complete system. It features a scientifically designed structure, professional appearance, space-saving design, and simple operation, making it ideal for customers with limited factory space and on-site construction projects.

Core Components
  • Feed introduction platform
  • Forming host
  • Forming and shearing device
  • Hydraulic station
  • Computer control system

Each component is precisely matched to ensure stable and efficient production performance.

Operation Features

Switching between upper and lower layers is extremely simple. Operators can control each layer separately using the conversion button on the electric control cabinet, or independently manage power through the clutch system for flexible production switching.

Customization Options

Optional configurations include ordinary unloading machines and hydraulic unloading machines to meet different production needs. The specific models of upper and lower layers can be fully customized according to customer requirements.

Technical Specifications
Model NO Double layer roll forming machine
Condition New
Usage Roof
External dimensions 6500mm x 1300mm x 1200mm
Machine frame 300H steel frame
Number of rolling mill sets 13-11 row molding
Roll material 45# steel rough lathe fine lathe outer circle grinding and electroplating treatment
Spindle material 45 steel
Spindle diameter Φ70mm (Solid shaft)
Type of Driven Chain drive
Forming Speed 0-35M/min
Main motor power 7.5KW
Electric control system PLC
Customized Customized
Origin Cangzhou, Hebei
Warranty 1 year
Raw materials Galvanized steel plate, color steel plate
Pull rod 35mm galvanized
Product Images
PLC Control Double Layer Forming Machine Hydraulic Pressure Transmission PLC Control Double Layer Forming Machine Hydraulic Pressure Transmission PLC Control Double Layer Forming Machine Hydraulic Pressure Transmission PLC Control Double Layer Forming Machine Hydraulic Pressure Transmission PLC Control Double Layer Forming Machine Hydraulic Pressure Transmission
Frequently Asked Questions
How many people are required to operate the machine?
It requires just one operator plus one person to handle the output; for highly automated models, a single person is sufficient.
What materials is this machine suitable for?
Cold-formed materials such as color-coated steel, galvanized steel, aluminum-magnesium-manganese alloy, and stainless steel.
What service can you provide before order?
We provide full pre-sales service, including answers to all your questions about our machines, such as technical parameters, price, payment terms, etc. If you would like to visit our factory and inspect the machines, we can send you an invitation letter and offer you our warmest welcome.
Is the length of the discharge rack adjustable?
Yes, our standard telescopic discharge rack can be adjusted to accommodate sheet materials of varying lengths.
How should the machine be stored when not in use for an extended period?
Disconnect the power, clean the machine, apply anti-rust oil, cover it with a dust cover, and store it in a dry environment.
